XP60 Projector
22 - English A26361-K865-Z100-1-5E19
Capture new
You can capture your own logo. Proceed as follows:
Ê Display the desired logo with the projector.
Ê Select the "Capture new" function.
Ê Select the range you want to display as the logo by moving the displayed frame with
the mouse ball over the logo.
Ê If necessary, adjust the frame to the logo size with the "Volume" buttons and confirm
the selection with the "Select" button.
Ê Select the picture quality (High = 18bit, Low = 4bit) and confirm with the "Select"
button.
The projector confirms that the capture was successful or reports an error.
Ê Restart the projector.
PiP menu (Picture in Picture)
In the PiP menu you can select the position and size of the
displayed picture.
PiP Enable
Select "PIP Enable" to activate the Picture in Picture mode and
select the size of the Picture in Picture (PiP).
PiP Position
You can move the video picture on your screen with this function.
