XP60 Projector
26 - English A26361-K865-Z100-1-5E19
DVI M1-D/A projector connection
1
9
17 24
C3
C4
C5
C2
C1
8
Pin Meaning Pin Meaning
1 TMDS Data 2- 13 not used
2 TMDS Data 2+ 14 +5 V Power
3 TMDS Data 2/4 Shield 15 Ground
4 not used 16 Hot Plug Detect
5 not used 17 TMDS Data 0-
6 DDC Clock 18 TMDS Data 0+
7 DDC Data 19 TMDS Data 0/5 Shield
8 Analogue Vertical Sync 20 not used
9 TMDS Data 1- 21 not used
10 TMDS Data 1+ 22 TMDS Clock Shield
11 TMDS Data 1/3 Shield 23 TMDS Clock-
12 not used 24 TMDS Clock+
C1 Analogue Red C4 Analogue Horizontal Sync
C2 Analogue Green C5 Analogue Ground
C3 Analogue Blue
