Working with the notebook
A26391-K147-Z120-1-7619 17
The meanings of the symbols are as follows:
Power-on indicator
• The indicator is green: The notebook is on.
• The indicator lights orange: The notebook is in energy-saving mode.
• The indicator is dark: The notebook is switched off.
Hard disk indicator
The indicator flashes green when the hard disk is accessed.
Battery indicator
• The indicator is green: The battery is fully charged, and the power adapter is
connected.
• The indicator flashes green ((1 second on; 3 seconds off): battery is being charged.
• The indicator is orange: the battery capacity is very low. The remaining operating
time is approx. 5 - 10 % of the battery capacity.
• The indicator flashes orange: The battery is nearly empty. The remaining operating
time is a maximum of 4 % of the battery capacity.
• The indicator is red: The battery is defective or temperature is extremely high/low.
• The indicator does not light up: the notebook runs on its built-in battery or the
notebook is switched off.
A
Caps Lock indicator
The Ø key has been pressed. All the characters you type appear in uppercase. In the
case of overlay keys, the character printed on the upper left of the key appears when that
key is pressed.
1
Num Lock indicator
The Num key has been pressed. The numeric keypad is activated. You can output the
characters located at the upper right on the keys.
Scroll indicator (Scroll Lock)
The key combination Fn + Scr has been pressed. The effect this key has varies from
programme to programme.
