Working with the notebook
16 A26391-K147-Z120-1-7619
Under side
1
2
3
4
5
1 = Hard disk
2 = Lock for battery lock
3 = Battery release latch
4 = Battery
5 = Memory cover
Status indicators
The status indicators provide information about the status of the power supply, the drives and the
keyboard functions.
Power-on indicator
A
Caps Lock indicator
Hard disk indicator
1
Num Lock indicator
Battery indicator
Scroll indicator (Scroll Lock)
