4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model:ASYG07LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 1.87 1.32 0.33 2.09 1.33 0.33 2.16 1.45 0.33 2.30 1.45 0.34 2.37 1.57 0.34 2.51 1.56 0.34 2.65 1.66 0.35
25 1.78 1.26 0.37 1.98 1.26 0.37 2.05 1.37 0.37 2.18 1.38 0.38 2.25 1.49 0.38 2.39 1.48 0.38 2.52 1.58 0.39
30 1.68 1.19 0.41 1.87 1.19 0.41 1.94 1.30 0.42 2.06 1.30 0.42 2.13 1.41 0.42 2.25 1.40 0.43 2.38 1.49 0.43
35 1.58 1.12 0.45 1.76 1.12 0.46 1.82 1.22 0.46 1.94 1.23 0.46 2.00 1.32 0.47 2.12 1.32 0.47 2.24 1.40 0.47
40 1.41 1.00 0.45 1.57 1.00 0.46 1.62 1.09 0.46 1.73 1.09 0.46 1.78 1.18 0.46 1.89 1.17 0.47 2.00 1.25 0.47
43 1.31 0.92 0.45 1.45 0.93 0.45 1.50 1.01 0.46 1.60 1.01 0.46 1.65 1.09 0.46 1.75 1.09 0.47 1.85 1.16 0.47
¢
Model:ASYG09LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 2.34 1.62 0.46 2.61 1.63 0.46 2.70 1.77 0.47 2.87 1.78 0.47 2.96 1.92 0.47 3.14 1.91 0.48 3.32 2.04 0.48
25 2.22 1.54 0.51 2.48 1.55 0.52 2.56 1.68 0.52 2.73 1.69 0.53 2.81 1.82 0.53 2.98 1.82 0.54 3.15 1.93 0.54
30 2.10 1.45 0.57 2.34 1.46 0.58 2.42 1.59 0.58 2.58 1.60 0.59 2.66 1.72 0.59 2.82 1.72 0.60 2.98 1.83 0.60
35 1.98 1.37 0.63 2.20 1.38 0.64 2.28 1.50 0.64 2.43 1.50 0.65 2.50 1.62 0.65 2.65 1.61 0.66 2.80 1.72 0.66
40 1.76 1.22 0.63 1.96 1.23 0.64 2.03 1.33 0.64 2.16 1.34 0.65 2.23 1.44 0.65 2.36 1.44 0.66 2.50 1.53 0.66
43 1.63 1.13 0.62 1.82 1.14 0.63 1.88 1.24 0.64 2.00 1.24 0.64 2.07 1.34 0.65 2.19 1.33 0.65 2.31 1.42 0.66
¢
Model:ASYG12LMCE
AFR
m
3
/h
750
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 3.18 2.18 0.66 3.55 2.19 0.67 3.67 2.39 0.68 3.91 2.39 0.68 4.03 2.59 0.69 4.27 2.57 0.70 4.51 2.74 0.70
25 3.03 2.07 0.75 3.37 2.08 0.77 3.49 2.27 0.77 3.72 2.27 0.78 3.83 2.45 0.78 4.06 2.44 0.79 4.29 2.60 0.80
30 2.86 1.96 0.84 3.19 1.97 0.86 3.30 2.14 0.86 3.52 2.15 0.87 3.63 2.32 0.87 3.84 2.31 0.88 4.06 2.46 0.89
35 2.69 1.84 0.94 2.99 1.85 0.95 3.09 2.01 0.96 3.30 2.02 0.97 3.40 2.18 0.97 3.60 2.17 0.98 3.81 2.31 0.99
40 2.27 1.64 0.87 2.53 1.65 0.88 2.62 1.79 0.89 2.79 1.80 0.90 2.87 1.94 0.90 3.05 1.94 0.91 3.22 2.06 0.92
43 2.09 1.52 0.87 2.33 1.53 0.89 2.41 1.66 0.89 2.57 1.67 0.90 2.65 1.80 0.90 2.81 1.80 0.91 2.96 1.91 0.92
¢
Model:ASYG14LMCE
AFR
m
3
/h
770
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
20 3.72 2.44 0.77 4.15 2.46 0.78 4.29 2.67 0.79 4.57 2.68 0.80 4.71 2.90 0.80 4.99 2.89 0.81 5.28 3.07 0.82
25 3.54 2.34 0.88 3.94 2.36 0.89 4.08 2.56 0.90 4.34 2.57 0.91 4.48 2.78 0.91 4.75 2.77 0.92 5.02 2.95 0.93
30 3.36 2.31 0.99 3.74 2.32 1.00 3.87 2.52 1.01 4.12 2.53 1.02 4.25 2.73 1.02 4.50 2.72 1.03 4.76 2.90 1.04
35 3.16 2.19 1.10 3.52 2.21 1.11 3.64 2.40 1.12 3.88 2.41 1.13 4.00 2.60 1.14 4.24 2.59 1.15 4.48 2.76 1.16
40 2.30 1.87 0.75 2.56 1.88 0.76 2.65 2.04 0.77 2.83 2.05 0.78 2.91 2.21 0.78 3.09 2.20 0.79 3.26 2.35 0.80
43 2.20 1.84 0.80 2.45 1.85 0.81 2.53 2.01 0.81 2.70 2.02 0.82 2.78 2.18 0.83 2.95 2.17 0.83 3.12 2.31 0.84
- 7 -
WALL MOUNTED ASYG07-14LMCE
