Fujitsu AOYG09LMCE Design & Technical Manual

1. Specifications
Type Inverter heat pump
Model name AOYG07LMCE AOYG09LMCE AOYG12LMCE AOYG14LMCE
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 3.3 3.5 4.8 6.3
Fan
Airflow rate
Cooling
m
3
/h
1,670 1,830 1,940
Heating 1,470 1,600 1,700
Type × Q'ty Propeller fan × 1
Motor output W 23 37
Sound pressure level *1
Cooling
dB (A)
45 50
Heating 45 50
Sound power level
Cooling
dB (A)
58 61 65
Heating 56 61 65
Heat exchanger type
Dimensions
(H × W × D)
mm
650 × 504 × 18.2 642 × 504 × 36.4 896 × 504 × 36.4
Fin pitch 1.3 1.4 1.3
Rows × Stages 1 × 24 2 × 24
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue fin)
Compressor
Type × Q'ty Rotary × 1
Motor output W 500 610 750
Refrigerant
Type (Global warming potential) R410A (1975)
Charge g 700 850 1,050
Refrigerant oil
Type POE (VG74)
Amount
cm
3
280
Enclosure
Material Steel sheet
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
535 × 663 × 293 540 × 790 × 290
Gross 595 × 790 × 395 648 × 938 × 400
Weight
Net
kg
21 26 34
Gross 25 30 37
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 43
Heating -15 to 24
Drain hose
Material PP+LLDPE LDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
Ø 13.0 (I. D.),
Ø 16.0 to Ø 16.7 (O.
D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 32 -
OUTDOOR UNIT AOYG07-14LMCE
