2. Dimensions
2-1. Models:ASYG07LMCE, ASYG09LMCE, ASYG12LMCE,
and ASYG14LMCE
Unit: mm
270
(270)
34218
209
74
870
204
(870)
426
310
444
165 144
178 233
321 315
295
Outline of unit
65 for pipe inlet
65 for pipe inlet
DESIGN & TECHNICAL MANUAL
- 4 -
WALL MOUNTED
ASYG07-14LMCE
