Fujitsu AOYG09LMCE Design & Technical Manual

6-3. Model:AOYG14LMCE
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 - - - 0.893 0.909
10 - - 0.955 0.908 0.924
7.5 - 0.975 0.959 0.912 0.928
5 0.992 0.979 0.963 0.916 0.931
0 1.000 0.987 0.970 0.923 0.939
Indoor unit is lower than
outdoor unit *2
-5 1.000 0.987 0.970 0.923 0.939
-7.5 - 0.987 0.970 0.923 0.939
-10 - - 0.970 0.923 0.939
-15 - - - 0.923 0.939
HEATING
Pipe length (m)
5 7.5 10 15 20
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 - - - 0.956 0.938
10 - - 1.004 0.956 0.938
7.5 - 1.013 1.004 0.956 0.938
5 1.000 1.013 1.004 0.956 0.938
0 1.000 1.013 1.004 0.956 0.938
Indoor unit is lower than
outdoor unit *2
-5 0.995 1.008 0.999 0.951 0.938
-7.5 - 1.005 0.997 0.948 0.931
-10 - - 0.994 0.946 0.929
-15 - - - 0.937 0.919
DESIGN & TECHNICAL MANUAL
- 44 -
OUTDOOR UNIT AOYG07-14LMCE
