2-2. Model:AOYG14LMCE
790
290
352
6820 10 18
Top view
540
320
209
Side view
Front view
Airflow
175
110
9
20
540
Drain pipe
mounting place
(ø20)
4-ø11.3mm hole
Bottom view
Unit: mm
DESIGN & TECHNICAL MANUAL
- 34 -
OUTDOOR UNIT
AOYG07-14LMCE
