01-13
(5) Press the SELECT button (SW108), and display the code number of the mode you want to get on the LED105.
*2 *2 *2
LED105 LED104 LED105 LED104 LED105 LED104
Cooling test operation Heating test operation Test operation stop
*2: Numbers other than 00-02 are used during maintenance. Please do not use during normal operation.
LED105 LED104 LED105 LED104
Once "done" has displayed, operation will start after a few minutes. With this, setting is complete.
After operation has started, verify according to "9.3. Checklist" provided below.
If you want to stop during test operation, set to test operation stop described in (5) above and execute.
Note
Test run will finish after about 60 minutes automatically.•
Test run may be stopped before operating for 60 minutes if an error occurs after a starting test run.•
Switching between heating and cooling is not possible during test operation.
If you want to change the operation mode, stop the test operation,
and change the operation mode once again with mode selection of step (5).
If switching between heating and cooling is done during test operation,
display as per the right figure will appear and settings will not change.
* After 5 seconds since the display of right figure, you can return to screen of step (5)
by holding the "Enter" switch.
•
LED105 LED104
(6) After confirming the operation mode you want to set, press ENTER button (SW109) for more than 3 seconds.
Ex.) To select the cooling test operation setting.
(7) After the completion of test operation, turn off the power, attach electrical components cover
and install front panel of outdoor unit.
