- (02 - 01) -
OUTDOOR UNIT
AOGA18-25FBTAH
OUTDOOR UNIT
AOGA18-25FBTAH
SPECIFICATIONS1.
NOTES:
Specications are based on the following conditions.
Cooling: Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB/24 °CWB.
Pipe length: 7.5 m, Height difference: 0 m.(Outdoor unit - Indoor unit)
The protective function may work when using it outside the operation range.
*: These are the measured values in the manufacturer’s anechoic chamber.
Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specied values here.
Type COOLING ONLY
Model name AOGA18FBTAH AOGA25FBTAH
Power source 220 / 240 V ~ 50 Hz
Available voltage range 198 to 264 V
Starting current A 42 55
Fan
Airow rate m
3
/h 3,200 3,300
Type × Q'ty Propeller × 1
Motor output W 75 59
Sound pressure level * Cooling dB(A) 54 54
Heat exchanger type
Dimensions (H × W × D)
mm
630 x 901 x 36.4 798 × 900 × 36.4
Fin pitch 1.45 1.30
Rows x Stages 2 × 30 2 × 38
Pipe type Copper
Fin type (Surface treatment) Aluminium (Blue n)
Compressor
Type × Q'ty Rotary × 1
Motor output W 1,330 1,670
Refrigerant
Type R410A
Charge g 1,500 1,800
Refrigerant oil Type RB75EA (POE)
Enclosure
Material Steel sheet
Colour
BEIGE
Approximate colour of MUNSELL 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
650 × 830 × 320 830 × 900 × 330
Gross 743 × 984 × 413 970 × 1050 × 445
Weight
Net
kg
50 63
Gross 54 70
Connection
pipe
Size
Liquid
mm
Ø 6.35 (Ø 1/4 in.)
Gas Ø 15.88 (Ø 5/8 in.)
Method Flare
Pre-charge length
m
7.5
Max. length 20 25
Max. height difference 8 15
Operation range Cooling ˚C 21 to 52
