Fujitsu ARHG12LLTB

En-14
*Autorestartisanemergencyfunctionsuchasforpowerfailureetc.Donotstartandstop
the indoor unit by this function in normal operation. Be sure to operate by the control unit,
or external input device.
(6) Indoor room temperature sensor switching function
(OnlyforWiredremotecontroller)
The following settings are needed when using the Wired remote controller temperature
sensor.
(♦...Factorysetting)
Setting description
Function
number
Setting value
♦
No
42
00
Yes 01
*Ifsettingvalueis“00”:
Room temperature is controlled by the indoor unit temperature sensor.
*Ifsettingvalueis“01”:
Room temperature is controlled by either indoor unit temperature sensor or remote
controller unit sensor.
(7) Wireless remote controller signal code
ChangetheindoorunitSignalCode,dependingonthewirelessremotecontrollers.
(♦...Factorysetting)
Setting description
Function
number
Setting value
♦
A
44
00
B 01
C 02
D 03
(8) External input control
“Operation/Stop”modeor“Forcedstop”modecanbeselected.
(♦...Factorysetting)
Setting description
Function
number
Setting value
♦
Operation/Stopmode
46
00
(Settingforbidden) 01
Forced stop mode 02
Setting record
•
Record any changes to the settings in the following table.
Setting Setting Value
(1)Filtersign
(2)Staticpressure
(3)Coolingroomtemperaturecorrection
(4)Heatingroomtemperaturecorrection
(5)Autorestart
(6)Indoorroomtemperaturesensorswitchingfunc-
tion
(7)Wirelessremotecontrollersignalcode
(8)Externalinputcontrol
After completing the FUNCTION SETTING, be sure to turn off the power and turn it on
again.
SETTING THE ROOM TEMPERATURE DETECTION
LOCATION
The detection location of the room temperature can be selected from the following 2 examples.
Choosethedetectionlocationthatisbestfortheinstallationlocation.
A. Indoor unit setting (factory setting)
The room temperature is detected by the indoor unit temperature sensor .
(1) WhentheTHERMOSENSORbuttonispressed,thelockdisplayashesbecausethe
function is locked at the factory.
A
Indoor unit
B. Indoor unit/remote controller setting (room tempera-
ture sensor selection)
The temperature sensor of the indoor unit or the remote controller can be used to detect
the room temperature.
(1) EnabletheroomtemperaturesensorselectioninFUNCTIONSETTING,whichwillbe
previous page.
(2) PresstheTHERMOSENSORbuttonfor5secondsormoretoselectthetemperature
sensor of the indoor unit or the remote controller.
B
Indoor unit
NOTES
IfthefunctiontochangethetemperaturesensorisusedasshowninexamplesA(other
thanexampleB),besuretolockthedetectionlocation.Ifthefunctionislocked,thelock
display
willashwhentheTHERMOSENSORbuttonispressed.
7.4. Jumper wire setting
(1) Drainage function setting (JM1)
If contained drainpumpisnotused,setthedrainagefunctionto“Invalid”inthedrainage
function switching.
Ifcontaineddrainpumpisnotuse:•
Whenusedunder“WALLMOUNTEDTYPE/FLOORSTANDINGCONCEALEDTYPE”.
Whenusedinnaturaldrainageunder“CEILINGCONCEALEDTYPE”.
(♦...Factorysetting)
JM1 Drainage function
♦
Connect Valid
Disconnect Invalid
(2) Auto louver grille setting (JM2) (Optional parts)
(♦...Factorysetting)
JM2 Auto louver grille setting
♦
Connect Invalid
Disconnect Valid
(3) Fan delay setting (JM3)
It is a function to delay the stop of cooling fan when the air conditioner is stopped.
(♦...Factorysetting)
JM3 Fan delay
♦
Connect Invalid
Disconnect Valid
• Switching position
JM3 JM2 JM1
Jumperwires
9374815173-04_IM.indb 14 9/21/2011 1:45:26 PM
