Fujitsu ARHG12LLTB

En-2
2.3. Accessories
WARNING
• Forinstallationpurposes,besure tousethepartssupplied bythemanufactureror
other prescribed parts.
The use of non-prescribed parts can cause serious accidents such as the unit to fall,
waterleakage,electricshock,orre.
• Thefollowinginstallationpartsarefurnished.Usethemasrequired.
• KeeptheInstallationManualinasafeplaceanddonotdiscardanyotheraccessories
until the installation work has been completed.
Do not discard any accessories needed for installation until the installation work has
been completed.
Name and Shape Q’ty Application
OperatingManual
1
InstallationManual
1
(Thisbook)
Installation
template
1
For positioning the indoor
unit
Washer
8
For installing indoor unit
Coupler
heat insulation
(Large)
1
For indoor side pipe joint
(Largepipe)
Coupler
heat insulation
(Small)
1
For indoor side pipe joint
(Smallpipe)
Binder
Medium
3
For power supply and
transmission and remote
controller cable binding.
Large
4
For fixing the coupler heat
insulation.
Filter(Small)
2
(7000,9000,12000,14000BTU/h)
Filter(Big)
2
(18000BTU/h)
Drain hose
1
For installing drain pipe
VP25(O.D.32,I.D.25)
Name and Shape Q’ty Application
Hoseband
1
For installing drain hose
Drain hose insulation B
1
Insulates the drain hose
Wired Remote
Controller
1
RemoteController
Cable
1
For connecting the
remote controller
Tapping screw
(M4×16mm)
2
For installing the remote
controller
2.4. Optional parts
Parts name Model No. Application
Wired remote controller UTY-RNN*M For air conditioner operation
SimpleRemoteController UTY-RSN*M For air conditioner operation
IRReceiverUnit UTY-LRH*M For the wireless remote controller
Remote sensor unit UTY-XSZX Room temperature sensor
External control set UTD-ECS5A Forcontrolinput/outputport
Auto louver grille UTD-G*S*-W Air outlet grille with auto louver
3. INSTALLATION WORK
3.1. Selecting an installation location
Especially, the installation place is very important for the split type air conditioner
becauseitisverydifculttomovefromplacetoplaceaftertherstinstallation.
WARNING
• Selectinstallationlocationsthatcanproperlysupporttheweightoftheindoor.Install
the units securely so that they do not topple or fall.
CAUTION
• Donotinstalltheunitinthefollowingareas:
• Areawithhighsaltcontent,suchasattheseaside.
It will deteriorate metal parts, causing the parts to fail or the unit to leak water.
• Arealledwithmineraloilorcontainingalargeamountofsplashedoilorsteam,
such as a kitchen.
It will deteriorate plastic parts, causing the parts to fail or the unit to leak water.
• Area that generates substances that adversely affect the equipment, such as
sulfuric gas, chlorine gas, acid, or alkali.
It will cause the copper pipes and brazed joints to corrode, which can cause
refrigerant leakage.
• Areathatcancausecombustiblegastoleak,containssuspendedcarbonbersor
ammabledust,orvolatileinammablessuchaspaintthinnerorgasoline.
 Ifgasleaksandsettlesaroundtheunit,itcancauseare.
• Areawhereanimalsmayurinateontheunitorammoniamaybegenerated.
• Do not use the unit for special purposes, such as storing food, raising animals,
growing plants, or preserving precision devices or art objects.
It can degrade the quality of the preserved or stored objects.
• Donotinstallwherethereisthedangerofcombustiblegasleakage.
• Donotinstalltheunitnearasourceofheat,steam,orammablegas.
• Installtheunitwheredrainagedoesnotcauseanytrouble.
• Install the indoor unit, outdoor unit, power supply cable, transmission cable, and
remotecontroller cableat least 1m awayfrom atelevisionor radioreceivers.The
purpose of this is to prevent TV reception interference or radio noise.
(Evenifthey areinstalledmore than1mapart,you couldstillreceive noiseunder
somesignalconditions.)
