Fujitsu ASU12RLF1

¢
Models: ASUH07LPAS, ASUH09LPAS, ASUH12LPAS,
ASUH15LPAS, ASUH18LPAS, and ASUH24LPAS
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Tapping screw (large) 5
Installation manual 1 Tapping screw (small) 2
Remote controller 1 Battery 2
Remote controller
holder
1 Wall hook bracket 1
Cloth tape 1 Ion deodorization filter 1
Filter holder 2 Apple-catechin filter 1
Seal A
• It is necessary when
using 15 model.
• It is used when the
diameter of gas pipe
is Ø1/2 in (12.70 mm)
or more.
1
Adapter,
1/2 (12.7)→5/8 (15.88)
[in (mm)]
(Only for 24 model)
1
- 224 -
17-3. Wall mounted type 17. Accessories
MULTI-SPLIT TYPE 5-unit type MULTI-SPLIT TYPE 5-unit type
