6. Capacity table
6-1. Combinations
¢ Model: AOU45RLXFZ
 Cooling
Combination of indoor unit
Type of in-
door unit
Rated capacity for each indoor
unit [kBtu/h]
Maximum capacity for each in-
door unit [kBtu/h]
Total capacity
[kBtu/h]
Input power [kW]
Unit
Total
Unit Unit
Min. Rated Max. Min. Rated Max.
1 2 3 4 5 1 2 3 4 5 1 2 3 4 5
12 24 — — — 36 Non-ducted 12.0 24.0 — — — 12.8 25.6 — — — 12.0 36.0 38.4 0.80 3.28 3.42
15 24 — — — 39 Non-ducted 15.0 24.0 — — — 16.0 25.6 — — — 12.0 39.0 41.6 0.80 3.72 3.89
18 18 — — — 36 Non-ducted 18.0 18.0 — — — 19.2 19.2 — — — 12.0 36.0 38.4 0.80 3.28 3.42
18 24 — — — 42 Non-ducted 18.0 24.0 — — — 19.2 25.6 — — — 12.0 42.0 44.8 0.80 4.17 4.36
24 24 — — — 48 Non-ducted 22.5 22.5 — — — 24.0 24.0 — — — 12.0 45.0 48.0 0.80 4.55 4.77
7 7 24 — — 38 Non-ducted 7.0 7.0 24.0 — — 7.5 7.5 25.6 — — 12.0 38.0 40.5 0.80 3.50 3.73
7 9 18 — — 34 Non-ducted 7.0 9.0 18.0 — — 7.5 9.6 19.2 — — 12.0 34.0 36.3 0.80 2.92 3.10
7 9 24 — — 40 Non-ducted 7.0 9.0 24.0 — — 7.5 9.6 25.6 — — 12.0 40.0 42.7 0.80 3.79 4.05
7 12 18 — — 37 Non-ducted 7.0 12.0 18.0 — — 7.5 12.8 19.2 — — 12.0 37.0 39.5 0.80 3.35 3.58
7 12 24 — — 43 Non-ducted 7.0 12.0 24.0 — — 7.5 12.8 25.6 — — 12.0 43.0 45.9 0.80 4.22 4.52
7 15 15 — — 37 Non-ducted 7.0 15.0 15.0 — — 7.5 16.0 16.0 — — 12.0 37.0 39.5 0.80 3.35 3.58
7 15 18 — — 40 Non-ducted 7.0 15.0 18.0 — — 7.5 16.0 19.2 — — 12.0 40.0 42.7 0.80 3.79 4.05
7 15 24 — — 46 Non-ducted 6.8 14.7 23.5 — — 7.3 15.7 25.0 — — 12.0 45.0 48.0 0.80 4.46 4.77
7 18 18 — — 43 Non-ducted 7.0 18.0 18.0 — — 7.5 19.2 19.2 — — 12.0 43.0 45.9 0.80 4.22 4.52
7 18 24 — — 49 Non-ducted 6.4 16.5 22.0 — — 6.9 17.6 23.5 — — 12.0 45.0 48.0 0.80 4.46 4.77
9 9 18 — — 36 Non-ducted 9.0 9.0 18.0 — — 9.6 9.6 19.2 — — 12.0 36.0 38.4 0.80 3.21 3.42
9 9 24 — — 42 Non-ducted 9.0 9.0 24.0 — — 9.6 9.6 25.6 — — 12.0 42.0 44.8 0.80 4.08 4.36
9 12 15 — — 36 Non-ducted 9.0 12.0 15.0 — — 9.6 12.8 16.0 — — 12.0 36.0 38.4 0.80 3.21 3.42
9 12 18 — — 39 Non-ducted 9.0 12.0 18.0 — — 9.6 12.8 19.2 — — 12.0 39.0 41.6 0.80 3.64 3.89
9 12 24 — — 45 Non-ducted 9.0 12.0 24.0 — — 9.6 12.8 25.6 — — 12.0 45.0 48.0 0.80 4.46 4.77
9 15 15 — — 39 Non-ducted 9.0 15.0 15.0 — — 9.6 16.0 16.0 — — 12.0 39.0 41.6 0.80 3.64 3.89
9 15 18 — — 42 Non-ducted 9.0 15.0 18.0 — — 9.6 16.0 19.2 — — 12.0 42.0 44.8 0.80 3.92 4.36
9 15 24 — — 48 Non-ducted 8.4 14.1 22.5 — — 9.0 15.0 24.0 — — 12.0 45.0 48.0 0.80 4.28 4.77
9 18 18 — — 45 Non-ducted 9.0 18.0 18.0 — — 9.6 19.2 19.2 — — 12.0 45.0 48.0 0.80 4.28 4.77
9 18 24 — — 51 Non-ducted 7.9 15.9 21.2 — — 8.5 16.9 22.6 — — 12.0 45.0 48.0 0.80 4.28 4.77
12 12 12 — — 36 Non-ducted 12.0 12.0 12.0 — — 12.8 12.8 12.8 — — 12.0 36.0 38.4 0.80 3.08 3.42
12 12 15 — — 39 Non-ducted 12.0 12.0 15.0 — — 12.8 12.8 16.0 — — 12.0 39.0 41.6 0.80 3.50 3.89
12 12 18 — — 42 Non-ducted 12.0 12.0 18.0 — — 12.8 12.8 19.2 — — 12.0 42.0 44.8 0.80 3.22 4.36
12 12 24 — — 48 Non-ducted 11.3 11.3 22.5 — — 12.0 12.0 24.0 — — 12.0 45.0 48.0 0.80 4.28 4.77
12 15 15 — — 42 Non-ducted 12.0 15.0 15.0 — — 12.8 16.0 16.0 — — 12.0 42.0 44.8 0.80 3.92 4.36
12 15 18 — — 45 Non-ducted 12.0 15.0 18.0 — — 12.8 16.0 19.2 — — 12.0 45.0 48.0 0.80 4.28 4.77
12 15 24 — — 51 Non-ducted 10.6 13.2 21.2 — — 11.3 14.1 22.6 — — 12.0 45.0 48.0 0.80 4.28 4.77
12 18 18 — — 48 Non-ducted 11.3 16.9 16.9 — — 12.0 18.0 18.0 — — 12.0 45.0 48.0 0.80 4.46 4.77
12 18 24 — — 54 Non-ducted 10.0 15.0 20.0 — — 10.7 16.0 21.3 — — 12.0 45.0 48.0 0.80 4.46 4.77
15 15 15 — — 45 Non-ducted 15.0 15.0 15.0 — — 16.0 16.0 16.0 — — 12.0 45.0 48.0 0.80 4.46 4.77
15 15 18 — — 48 Non-ducted 14.1 14.1 16.9 — — 15.0 15.0 18.0 — — 12.0 45.0 48.0 0.80 4.46 4.77
15 15 24 — — 54 Non-ducted 12.5 12.5 20.0 — — 13.3 13.3 21.3 — — 12.0 45.0 48.0 0.80 4.46 4.77
15 18 18 — — 51 Non-ducted 13.2 15.9 15.9 — — 14.1 16.9 16.9 — — 12.0 45.0 48.0 0.80 4.46 4.77
18 18 18 — — 54 Non-ducted 15.0 15.0 15.0 — — 16.0 16.0 16.0 — — 12.0 45.0 48.0 0.80 4.46 4.77
7 7 7 15 — 36 Non-ducted 7.0 7.0 7.0 15.0 — 7.5 7.5 7.5 16.0 — 12.0 36.0 38.4 0.80 3.14 3.42
7 7 7 18 — 39 Non-ducted 7.0 7.0 7.0 18.0 — 7.5 7.5 7.5 19.2 — 12.0 39.0 41.6 0.80 3.57 3.89
7 7 7 24 — 45 Non-ducted 7.0 7.0 7.0 24.0 — 7.5 7.5 7.5 25.6 — 12.0 45.0 48.0 0.80 4.37 4.77
7 7 9 12 — 35 Non-ducted 7.0 7.0 9.0 12.0 — 7.5 7.5 9.6 12.8 — 12.0 35.0 37.3 0.80 3.00 3.26
7 7 9 15 — 38 Non-ducted 7.0 7.0 9.0 15.0 — 7.5 7.5 9.6 16.0 — 12.0 38.0 40.5 0.80 3.43 3.73
7 7 9 18 — 41 Non-ducted 7.0 7.0 9.0 18.0 — 7.5 7.5 9.6 19.2 — 12.0 41.0 43.7 0.80 3.86 4.20
7 7 9 24 — 47 Non-ducted 6.7 6.7 8.6 23.0 — 7.1 7.1 9.2 24.5 — 12.0 45.0 48.0 0.80 4.37 4.77
7 7 12 12 — 38 Non-ducted 7.0 7.0 12.0 12.0 — 7.5 7.5 12.8 12.8 — 12.0 38.0 40.5 0.80 3.43 3.73
7 7 12 15 — 41 Non-ducted 7.0 7.0 12.0 15.0 — 7.5 7.5 12.8 16.0 — 12.0 41.0 43.7 0.80 3.86 4.20
7 7 12 18 — 44 Non-ducted 7.0 7.0 12.0 18.0 — 7.5 7.5 12.8 19.2 — 12.0 44.0 46.9 0.80 4.28 4.67
7 7 12 24 — 50 Non-ducted 6.3 6.3 10.8 21.6 — 6.7 6.7 11.5 23.0 — 12.0 45.0 48.0 0.80 4.37 4.77
7 7 15 15 — 44 Non-ducted 7.0 7.0 15.0 15.0 — 7.5 7.5 16.0 16.0 — 12.0 44.0 46.9 0.80 4.28 4.67
7 7 15 18 — 47 Non-ducted 6.7 6.7 14.4 17.2 — 7.1 7.1 15.3 18.4 — 12.0 45.0 48.0 0.80 4.28 4.77
7 7 15 24 — 53 Non-ducted 5.9 5.9 12.7 20.4 — 6.3 6.3 13.6 21.7 — 12.0 45.0 48.0 0.80 4.28 4.77
7 7 18 18 — 50 Non-ducted 6.3 6.3 16.2 16.2 — 6.7 6.7 17.3 17.3 — 12.0 45.0 48.0 0.80 4.28 4.77
7 9 9 9 — 34 Non-ducted 7.0 9.0 9.0 9.0 — 7.5 9.6 9.6 9.6 — 12.0 34.0 36.3 0.80 2.80 3.10
7 9 9 12 — 37 Non-ducted 7.0 9.0 9.0 12.0 — 7.5 9.6 9.6 12.8 — 12.0 37.0 39.5 0.80 3.22 3.58
7 9 9 15 — 40 Non-ducted 7.0 9.0 9.0 15.0 — 7.5 9.6 9.6 16.0 — 12.0 40.0 42.7 0.80 3.64 4.05
7 9 9 18 — 43 Non-ducted 7.0 9.0 9.0 18.0 — 7.5 9.6 9.6 19.2 — 12.0 43.0 45.9 0.80 3.30 4.52
7 9 9 24 — 49 Non-ducted 6.4 8.3 8.3 22.0 — 6.9 8.8 8.8 23.5 — 12.0 45.0 48.0 0.80 4.28 4.77
7 9 12 12 — 40 Non-ducted 7.0 9.0 12.0 12.0 — 7.5 9.6 12.8 12.8 — 12.0 40.0 42.7 0.80 3.64 4.05
7 9 12 15 — 43 Non-ducted 7.0 9.0 12.0 15.0 — 7.5 9.6 12.8 16.0 — 12.0 43.0 45.9 0.80 4.05 4.52
7 9 12 18 — 46 Non-ducted 6.8 8.8 11.7 17.6 — 7.3 9.4 12.5 18.8 — 12.0 45.0 48.0 0.80 4.28 4.77
7 9 12 24 — 52 Non-ducted 6.1 7.8 10.4 20.8 — 6.5 8.3 11.1 22.2 — 12.0 45.0 48.0 0.80 4.37 4.77
7 9 15 15 — 46 Non-ducted 6.8 8.8 14.7 14.7 — 7.3 9.4 15.7 15.7 — 12.0 45.0 48.0 0.80 4.37 4.77
7 9 15 18 — 49 Non-ducted 6.4 8.3 13.8 16.5 — 6.9 8.8 14.7 17.6 — 12.0 45.0 48.0 0.80 4.37 4.77
7 9 18 18 — 52 Non-ducted 6.1 7.8 15.6 15.6 — 6.5 8.3 16.6 16.6 — 12.0 45.0 48.0 0.80 4.37 4.77
7 12 12 12 — 43 Non-ducted 7.0 12.0 12.0 12.0 — 7.5 12.8 12.8 12.8 — 12.0 43.0 45.9 0.80 4.14 4.52
7 12 12 15 — 46 Non-ducted 6.8 11.7 11.7 14.7 — 7.3 12.5 12.5 15.7 — 12.0 45.0 48.0 0.80 4.37 4.77
7 12 12 18 — 49 Non-ducted 6.4 11.0 11.0 16.5 — 6.9 11.8 11.8 17.6 — 12.0 45.0 48.0 0.80 4.37 4.77
7 12 15 15 — 49 Non-ducted 6.4 11.0 13.8 13.8 — 6.9 11.8 14.7 14.7 — 12.0 45.0 48.0 0.80 4.37 4.77
7 12 15 18 — 52 Non-ducted 6.1 10.4 13.0 15.6 — 6.5 11.1 13.8 16.6 — 12.0 45.0 48.0 0.80 4.37 4.77
7 15 15 15 — 52 Non-ducted 6.1 13.0 13.0 13.0 — 6.5 13.8 13.8 13.8 — 12.0 45.0 48.0 0.80 4.37 4.77
9 9 9 9 — 36 Non-ducted 9.0 9.0 9.0 9.0 — 9.6 9.6 9.6 9.6 — 12.0 36.0 38.4 0.80 3.14 3.42
9 9 9 12 — 39 Non-ducted 9.0 9.0 9.0 12.0 — 9.6 9.6 9.6 12.8 — 12.0 39.0 41.6 0.80 3.57 3.89
