Fujitsu ASU24CL1 User Manual

- (01 - 08) -
WALL MOUNTED TYPE ASU2 4CL1 WALL MOUNTED TYPE ASU2 4CL1
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: ASU24CL1
AFR: Air ow rate (CFM)
TC: Total capacity (kBTU)
SHC: Sensible heat capacity (kBTU)
PI: Power input (kW))
AFR : Air ow rate (m
3
/min)
TC : Total capacity (kW)
SHC : Sensible heat capacity (kW)
PI : Power input (kW)
AFR 659
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
15.0 19.7 15.7 1.04 21.9 15.8 1.05 22.7 17.1 1.05 24.9 18.6 1.07 26.4 18.5 1.07 27.9 19.7 1.08
67 19.7 15.3 1.20 21.1 15.4 1.22 21.8 16.7 1.23 24.0 18.1 1.25 25.4 18.1 1.26 26.9 19.3 1.27
77 21.0 17.9 1.88 23.4 18.0 1.91 24.2 19.6 1.92 26.5 21.2 1.95 28.1 21.2 1.97 29.7 22.5 1.99
87 20.0 16.7 2.10 22.3 16.8 2.13 23.0 18.2 2.14 25.3 19.8 2.17 26.8 19.7 2.20 28.3 21.0 2.22
95 19.0 15.3 2.32 21.1 15.4 2.35 21.8 16.8 2.36 24.0 18.2 2.40 25.4 18.1 2.43 26.9 19.3 2.45
104 17.0 12.8 2.50 19.0 12.8 2.54 19.6 14.0 2.55 21.6 15.1 2.59 22.9 15.1 2.62 24.2 16.1 2.64
115 16.0 11.3 2.53 17.8 11.4 2.57 18.5 12.4 2.58 20.3 13.5 2.62 21.5 13.4 2.64 22.7 14.3 2.67
AFR 18.7
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
15.0 5.77 4.59 1.04 6.42 4.62 1.05 6.65 5.02 1.05 7.31 5.44 1.07 7.74 5.41 1.07 8.18 5.77 1.08
19.4 5.55 4.48 1.20 6.18 4.51 1.22 6.39 4.90 1.23 7.02 5.31 1.25 7.44 5.30 1.26 7.87 5.64 1.27
25.0 6.14 5.24 1.88 6.84 5.27 1.91 7.08 5.74 1.92 7.78 6.22 1.95 8.24 6.20 1.97 8.71 6.61 1.99
30.6 5.85 4.88 2.10 6.52 4.91 2.13 6.74 5.35 2.14 7.41 5.79 2.17 7.85 5.78 2.20 8.30 6.15 2.22
35.0 5.55 4.49 2.32 6.19 4.52 2.35 6.40 4.92 2.36 7.03 5.33 2.40 7.45 5.31 2.43 7.87 5.66 2.45
40.0 4.99 3.74 2.50 5.56 3.77 2.54 5.75 4.10 2.55 6.32 4.44 2.59 6.70 4.43 2.62 7.08 4.72 2.64
46.1 4.69 3.32 2.53 5.23 3.34 2.57 5.41 3.64 2.58 5.94 3.94 2.62 6.30 3.93 2.64 6.65 4.19 2.67
