Fujitsu ASU24CL1 User Manual

- (02 - 01) -
OUTDOOR UNIT AOU24CL1 OUTDOOR UNIT AOU24CL1
SPECIFICATIONS 1.
Type COOLING ONLY INVERTER
Model name AOU24CL1
Power source 208/230V ~ 60Hz
Available voltage range 187-253V ~ 60Hz
Starting current A 10.5
Fan
Airow
rate
Cooling
CFM
(m
3
/h)
1,554 (2,640)
Type × Q'ty Propeller fan×1
Motor output W 40
Sound pressure level Cooling dB(A) 56
Heat exchanger type
Dimensions (H × W × D)
inch 23-1/8 × 34-11/16 × 1-7/16
mm 588 × 881 × 36.4
Fin pitch mm 1.3
Rows × Stages 2 × 28
Pipe type Copper
Fin
Type(Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance (Blue n)
Compressor
Type × Q'ty Rotary × 1
Motor output W 1,100
Refrigerant
Type R410A
Charge
lb.oz. 2 lb. 13.9 oz.
kg 1.3
Refrigerant oil Type POE (VG74)
Enclosure
Material Steel
Color
BEIGE
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm 620 × 790 × 298
inch 24-7/16 × 31-1/8 × 11-3/4
Gross
mm 712 × 935 × 400
inch 28-1/16 × 36-13/16 × 15-3/4
Weight
Net
lb.(kg)
88 (40)
Gross 97 (44)
Connection pipe
Size
Liquid
inch
(mm)
Ø1/4 (Ø6.35)
Gas Ø5/8 (Ø15.88)
Method Flare
Max. length
ft.
(m)
98 (30) [chargeless: 49 (15)]
Max. height difference 66 (20)
Operation range Cooling °F (°C) 14 to 115 (-10 to 46)
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F (26.7 °C)DB / 67°F (19.4 °C)WB and outdoor temperature of 95°F (35 °C)DB / 75°F(23.9 °C)WB.
Pipe length : 25ft. (7.5 m), Height difference : 0 m.(Outdoor unit - Indoor unit)
