- (01 - 17) -
WALL MOUNTED TYPE
ASU2 4CL1
WALL MOUNTED TYPE
ASU2 4CL1
FUNCTION SETTING12.
INDOOR UNIT 12-1.
SWITCH POSITION
MAIN PCB
JM5
JM6
JM7
JM8
JM10
JM5
JM6
JM7
JM8
JM10
INDOOR UNIT
Jumper Wire
JM 5 Auto restart
JM 6
Room temperature correction
JM 7
JM 8
Remote controller signal code
JM 10
