Fujitsu ASU24CL1 - 4. DIMENSIONS; INSTALLATION PLACE

- (01 - 06) -
WALL MOUNTED TYPE ASU2 4CL1 WALL MOUNTED TYPE ASU2 4CL1
DIMENSIONS4.
MODEL

: ASU24CL1
Unit : in. (mm)
INSTALLATION PLACE

Unit : in. (mm)
2-15/32 (63) or more
3-5/32 (80) or more
2-3/32 (53) or more
2-1/16 (52) or more
3-5/32 (80) or more
Outline of unit
4-23/32 (120) or more
59-1/16 (1,500) or more
70-7/8 (1,800) or more
39-9/32 (998)
8-31/32
(228)
12-19/32 (320)
