- (02 - 06) -
OUTDOOR UNIT
AOU24CL1
OUTDOOR UNIT
AOU24CL1
ADDITIONAL CHARGE CALCULATION6.
MODEL
: AOU24CL1
Refrigerant charge
z
Refrigerant type R410A
Refrigerant amount
lb. oz. 2lb. 13.9oz.
g 1300
Pipe length
ft. ~ 49 66 82 98
0.22oz./ft.
(20g/m)
m ~ 15 20 25 30
Additional charge
oz. 0 (Charge less) 3.5 7.1 10.6
g 0 (Charge less) +100 +200 +300
