- 63 -
OUTDOOR UNIT
AOU30RLXEH
Multiple outdoor unit installation
•
When the upper space is open:
•
When there is an obstruction in the upper spa
ce:
Unit: in (mm)
When there are obst
acles at the rear only
.
When there are obst
acles at the front only
.
When there
are obstacles at the
front and rear.
Unit: in (mm)
When there are ob
stacles at the rear and above
.
12 (300) or more
60 (1,500)
or more
20 (500)
or more
60 (1,500)
or more
60 (1,500) or more
60 (1,500)
or more
20 (500) or more
Max. 11 (300)
66
68
