Fujitsu B19-7 LED User Manual

Your LCD screen...
Further information
Details of how you set the resolution and refresh rate are provided in the do cumentation
for your display adapter and the associated driver software.
For ergonomic r easons, a screen resolution of 1280 x 1024 pixels is recommended.
Because of the technology used (active matrix) an L CD monitor provides a to tally
flicker-free picture even with a refresh rate of 60 Hz.
Notational conventions
Pay particu lar attention to text ma rked with t his symbol. Failure to observe
these warnings could p ose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates importan t information for the proper use of the device.
►
Indicates an activity that must be performed

Indicates a result
This font
Indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font
Indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This fo n t
Indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e. g. Windows or setup.exe.
"This fon
t"
Indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source , e.g. a web address: F or more
information, go to "
http://www.fujitsu.com/fts/"
• Names of CDs, DVDs and titles o r designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key
Indicates a button on the monitor, e.g:
MENU
This
font
Indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
6 Fujitsu

Fujitsu B19-7 LED Specifications

General

3D	No
HD type	-
Pixel pitch	0.293 x 0.293 mm
Aspect ratio	5:4
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LED
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	480p
Contrast ratio (dynamic)	2000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1280 x 1024 (SXGA)
Rotating	Yes
Active display area (W x H)	375 x 300 mm
Mean time between failures (MTBF)	70000 h
Cables included	AC, Audio (3.5mm), DVI, VGA
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Number of OSD languages	19
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
HDMI ports quantity	0
DVI-D ports quantity	1
Headphone connectivity	3.5 mm
RMS rated power	3 W
Number of speakers	2
Sustainability certificates	EPEAT Gold, ENERGY STAR
Certification	CE certification according to EC Directive 2004/108/EEC, EN 60950, RoHS, WEEE, IT-Eco- Declaration, EN 60601-1-2, TÜV GS, EAC, FCC Class B, cUL, VCCI, KC (planned), TÜV-S, S-Mark, BSMI (planned), CCC, SASO, ISO9241-307 (Pixel fault class I), TCO Displays 6.0
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	22 kWh
Power consumption (standby)	- W
Power consumption (typical)	15 W
Power consumption (PowerSave)	0.23 W
Package weight	7200 g
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64
Operating temperature (T-T)	5 - 35 °C
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	209 mm
Height (with stand)	370 mm
Weight (with stand)	5480 g
Depth (without stand)	64 mm
Width (without stand)	414 mm
Height (without stand)	349 mm
Weight (without stand)	2850 g
