Tech nical specification
Environmental conditions
Environment class 3K2, D IN IEC 721
Rated range of operation
Humidity
15 °C .... 35 °C
20 % .... 85 %
Limit range of opera tion
Humidity
5 °C .... 35 °C
15 % .... 85 %
VESA-DDC-compatible VGA interface
Your monitor is equipped with a VESA-D DC-comp atible VGA interf ace. VESA-DDC (Video
Electronics Standard Association, Display Dat a Channel) is used as the communications
interface between the monitor and the computer. If the computer is eq uipped with a
VESA-DDC-compatible VGA interface, it can automatically read the data for ensuring
optimum operation from the monitor and select the appropriate s ettings.
Preset operating modes
The picture posit
ion and size have been set to optimum values at the factory for the
operating m odes l
isted above. Depend ing on the display adapter used, it m ay be
necessary to adj
ust the display position o r s ize. In this case, you can change and
save the settin
gs (see chapter "
Changing the monitor settings", Page 21).
For ergonomic r
easons, a screen resolution of 1280 x 1024 pixels is r eco mmended.
Duetothetech
nology used (active matrix) an LCD monitor provides a totally
flicker-free p
icture even with a refresh rate of 60 Hz.
Most frequent operating modes
Horizontal frequency Refresh rate Screen resolution
31.5 kHz 70 Hz 720 x 400
31.5 kHz 60 Hz 640 x 480
37.5 kHz 75 Hz 640 x 480
37.9 kHz 60 Hz 800 x 600
46.9 kHz 75 Hz 800 x 600
48.4 kHz 60 Hz 1280 x 1024
60.0 kHz 75 Hz 1280 x 1024
64.0 kHz 60 Hz 1280 x 1024
80.0 kHz 75 Hz 1280 x 1024
34 Fujitsu
