Tech nical data
Port Replicator (optional)
Electrical data
Safety regulations
complied with
CE, CB
Protection class II
Dimensions/weight
Width x depth x h eight
(front/back)
379 mm x 118 mm x 14/40 mm
Weight approx. 55 0 g
Ports
LAN port RJ45 socket
VGA port
15-pin socket
DisplayPort 20-pin socket
Parallel port 25-pin socket
Serial port
9-pin connector
Microphone port 3.5 mm mono mini-jack
Headphones port 3.5 mm mono mini-jack
FireWire port
4-pin S400
USB port 4 x USB 2.0
eSATA port
1x
Docking port 100-pin
Ambient conditions
Environment class
DIN IEC 721
3K2
Mechanical class
DIN IEC 721
7M2
Temperature:
Operation 5 °C ... 35 °C
Transportation
-15 °C ..
.60°C
84 Fujitsu Technology Solutions
