Fujitsu CELSIUS H910 - Removing a Hard Disk; Installing a Hard Disk

Removing and inst alling components
during servicing
Removing a hard disk
1
1
2
► Remove the screws (1).
► Lift the hard disk ou t of the hard disk compartment (2).
Installing a hard disk
2
2
1
► Place the hard d isk into the hard disk compartment (1).
► Tigh
ten the screws (2).
Fujitsu Technology Solutions 69
