Fujitsu CELSIUS H910 - Removing a Hard Disk; Installing a Hard Disk

Removing and installing com ponents
during servicing
Removing a hard disk
2
1
1
► Remove the screws (1).
► Lift the hard disk out of the hard disk compartment (2).
Installing a hard disk
1
2
2
► Place the hard disk into the hard disk compa rtment (1).
► Tigh
ten the screws (2).
72 Fujitsu Technology Solutions
