Fujitsu CELSIUS H970 User Manual

Contents
Settings in BIOS Setup Utility . . . ....................................................... 68
StartingtheBIOSSetup Utility ........................................................... 68
OperatingBIOSSetup Utility ............................................................. 69
ExitingBIOSSetupUtility ................................................................ 70
Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 70
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . . .............. 70
Load Setup Defaults – Copy Standard Entries . ........................................ 70
Discard Changes – Discard changes without exiting the BIOS Setup Utility . .............. 70
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 70
Save Changes and Power Off ....................................................... 70
Troubleshootingandtips .............................................................. 71
Help if problemsoccur ................................................................... 71
Restoring the hard disk contents under Windows . . ........................................ 72
The notebook’s date or time is incorrect ................................................... 72
The notebook’s LCD screen remains blank . . . . ............................................ 73
The LCD screen is difficulttoread ........................................................ 73
The externalmonitorremains blank ...................................................... 73
The externalmonitorisblankorthe imageisunstable ..................................... 74
The notebook cannot be started . . . ....................................................... 74
The notebook stops working . . ........................................................... 75
The printer does not print . . . . . ........................................................... 75
The wireless connection to a network does not work . . . .................................... 75
Acousticwarnings ....................................................................... 76
SmartCard reader is not recognised. . . . ................................................... 76
SmartCardPINforgotten ................................................................ 76
SmartCardlost ......................................................................... 76
Error messagesonthescreen ........................................................... 77
Technicaldata ......................................................................... 79
Notebook computer . . . .................................................................. 79
Rechargeablebattery ................................................................... 79
Mains adaptor (notebook computer) . . . ................................................... 79
Mains adaptor (port replicator) ........................................................... 80
Manufacturer’snotes .................................................................. 81
Disposalandrecycling .................................................................. 81
Certificationmarkings ................................................................... 81
Index .................................................................................. 82
Fujitsu 5

Fujitsu CELSIUS H970 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Panel type	TFT
LED backlight	Yes
Display surface	Matt
Display diagonal	17.3 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Pointing device	Touchpad
Operating system architecture	64-bit
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-6820HQ
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6800 Mobile Series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Optical drive type	DVD±RW
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, SD, SDHC, SDXC
Number of SSDs installed	1
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® P3000
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	6 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Audio chip	Realtek ALC255
Number of built-in speakers	2
Front camera resolution (numeric)	2 MP
Battery life (max)	9 h
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	13 A
AC adapter output voltage	19.5 V
Cable lock slot type	Kensington
Password protection type	HDD, Supervisor, User
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE
Processor code	SR2FU
Processor ARK ID	88970
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00

Weight and Dimensions

Depth	288 mm
Width	418 mm
Height	30 mm
Weight	- g
