Fujitsu D3598 - USB Type-C Port (D3598 Motherboard)

Mainboard D3598 English - 23
USB Type-C port (D3598 Motherboard)
Pin Signal Pin Signal
A1 GND B1 GND
A2 USB3_TX1 positive B2 USB3_TX2 positive
A3 USB3_TX1 negative B3 USB3_TX2 negative
A4 VCC AUX B4 VCC AUX
A5 Config. Channel 1 B5 Config. Channel 2
A6 USB2 Data positive B6 USB2 Data positive
A7 USB2 Data negative B7 USB2 Data negative
A8 Sideband1 B8 Sideband2
A9 VCC AUX B9 VCC AUX
A10 USB3_RX2 negative B10 USB3_RX1 negative
A11 USB3_RX2 positive B11 USB3_RX1 positive
A12 GND B12 GND
A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12
GND TX1+ TX1- V
BUS
CC1 D+ D- SBU1 V
BUS
RX2- RX2+ GND
GND RX1+ RX1- V
BUS
SBU2 D- D+ CC2 V
BUS
TX2- TX2+ GND
B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1
