7.5MultifeedDetectionConditions(1)
fi-5120C / fi-5220C Image Scanner Operator Guide
TROUBLE SHOOTING
CONTENTS MAP
TOP

7.5MultifeedDetectionConditions(1)


1
2
There are three multi feed detection modes: document overlapping, document length, and both document thickness and
length. The following conditions must be satisfied in each of these detection modes.
Detection by Document Overlapping
Sheets of the same thickness shall be set in the ADF at a time.
● Document thickness: 0.065 to 0.15mm
● Punched holes are not allowed within 35mm of the vertical center line of the document.
● Other paper shall not be glued within 35 mm (1.4 in) of the vertical centerline of the document.
Detection by Document Length
Sheets of the same length shall be set in the ADF at a time.
● Document length deviation: 1% or less
● Punched holes are not allowed within 35mm of the vertical center line of the document.
Detection by Document Overlapping and Length
Sheets of the same thickness and length shall be set in the ADF at a time.
● Document thickness: 0.065 to 0.15mm
● Document length deviation: 1% or less
● Punched holes are not allowed within 35mm of the vertical center line of the document.
● Other paper shall not be glued within 35 mm (1.4 in) of the vertical centerline of the document.
ATTENTION
Multifeed detection by overlap will often mis-detect very thick paper or plastic document.
When scanning documents like this, please disable the multifeed detection.

1
2

AllRightsReservedCopyright2006©PFULIMITED
file://///Hd-htgle21/Manual/fi-5120C5220C-lynx2/OG/R03/contents/EN/07/c070501.htm2006/08/2916:02:04

Fujitsu fi-5220C Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	24 bit
Maximum scan size	210 x 297 mm
Optical scanning resolution	600 x 600 DPI
Flatbed scan speed (b/w, A4)	2 sec/page
Scanner type	Flatbed & ADF scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	SCSI, USB 2.0
Bundled software	-FJ TWAIN driver. -Scandall. -Adobe Acrobat. -ISIS Driver. -QuickScan (demo). -Soft IPC (demo). -VRS 4.1 Basic.
Dimensions (WxDxH)	302 x 569 x 229 mm
Power requirements	100-240 VAC
Power consumption (standby)	6 W
Power consumption (typical)	34 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Weight	8400 g
