fi-5900C & fi-5950 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
6
REPLACING THE PICK ROLLERS (CONT.)
• Install the new Pick Rollers
by aligning the hole in the
rollers with the roller shaft.
Note:
The roller shaft and the hole in
the Pick Rollers are keyed and
will only slide on in one
orientation.
• Close the Roller Cover.
• Close the ADF Cover.
• Reset the Pick Roller
Counter in the Software
Operation Panel.
