Fujitsu MCJ3230AP - Table 4.55 Changeable Values in Flexible Disk Page; Table 4.56 Default Values in Flexible Disk Page

4.6 Packet Commands
C156-E205-01EN 4-49
Table 4.55 Changeable values in flexible disk page
Bit
Byte
76543210
2-3 0000h
4 00h
5 00h
6-7 00h
8-9 0000h
10-19 0000h
20 00h
21-27 00h
28-29 0000h
30-31 00h
Table 4.56 Default values in flexible disk page
Bit
Byte
76543210
2-3 3E80h
4 40h
5 20h
6-7 In case of 640 Mbytes, 1.3 Gbytes and 2.3 Gbytes media = 800h
Others or Not Ready = 200h
8-9
Number of LBA for media / (40h " 20h)
In case of Not Ready = the value of the maximum capacity media among the
supported 512 sectors media
10-19 00h
20 FFh
21-27 00h
28-29 1194h
30-31 00h
