4.6 Packet Commands
C156-E205-01EN 4-77
4.6.26 WRITE LONG command
Table 4.116 WRITE LONG command
Bit
Byte
76543210
0 Operation Code (3Fh)
1Reserved
2-5 Logial Block Address
6Reserved
7-8 Byte Transfer Length
9-11 Reserved
The WRITE LONG command writes data in the data, CRC, and ECC sections to
the specified logical block address.
The transfer byte length must be a multiple of 600 (258h) bytes for 512 byte media
and a multiple of 2380 (94Ch) bytes for 2048 byte media.
