C156-E205-01EN 5-1
CHAPTER 5 Operation and Cleaning
This chapter describes how to operate and clean the drive and the optical disk
cartridges.
5.1 Operating Optical Disk Drive
The drive has an automatic load function. All the operator must do is to insert the
optical disk cartridge and operate the eject button.
This section explains loading and ejection methods, assuming that the drive is
mounted horizontally. When mounted vertically, the drive is operated in the same
manner as when mounted horizontally.
Figure 5.1 shows the front view of the optical disk drive. For operation, users
should be familiar with the parts in the figure and their function. Loading and
ejection methods are described below.
5.1 Operating Optical Disk Drive
5.2 Cleaning Drive
5.3 Optical Disk Cartridge Operation
5.4 Cleaning Optical Disk Cartridge
