Installation Requirements
3-2 C156-E205-01EN
(a) Inside optical disk cartridge
(b) IC (controller, read amp)
Hole for inserting thermocouple
Tip of thermocouple
Operating of inner
partition wall
IC (controller)
IC (read amp)
IC (power amp)
Figure 3.1 Surface temperature measurement points
