Specifications
2-8 C156-E205-01EN
2.2.2 Optical disk cartridge
Figure 2.1 shows an optical disk cartridge. The figure below shows the cartridge
with its shutter open.
$
Shutter closed
$
Shutter open
Figure 2.1 Optical disk cartridge
3) Write protect tab
1) Cartridge case
2) Shutter
4) Disk
5) Hub
