BX920 S2 Options Guide 39
Mezzanine cards
As a result, the rules for populating the mezzanine card slots are as follows:
– If a 1 Gb Ethernet mezzanine card is installed in slot 1, at least one
1 Gb Ethernet connection blade must be installed in fabric 2.
– If a 10 Gb Ethernet mezzanine card is installed in slot 1, at least one
10 Gb Ethernet connection blade must be installed in fabric 2.
System unit
Connection blade slots Server Blade
Mezzanine
card
Fabric 1
CB1:
1 Gb Ethernet
or
10 Gb Ethernet
CB2:
1 Gb Ethernet
or
10 Gb Ethernet
Onboard
LAN controller
---
Fabric 2
CB3:
1 Gb Ethernet
CB4:
1 Gb Ethernet
Mezzanine
card 1
Eth 1 Gb 4 port
Fabric 3
CB5: CB6:
Mezzanine
card 2
Fabric 4
CB7: CB8:
System unit
Connection blade slots Server Blade
Mezzanine
card
Fabric 1
CB1:
1 Gb Ethernet
or
10 Gb Ethernet
CB2:
1 Gb Ethernet
or
10 Gb Ethernet
Onboard
LAN controller
---
Fabric 2
CB3:
10 Gb Ethernet
CB4:
10 Gb Ethernet
Mezzanine
card 1
Eth 10 Gb 2 port
Fabric 3
CB5: CB6:
Mezzanine
card 2
Fabric 4
CB7: CB8:
