42 Options Guide BX920 S2
Mezzanine cards
– If an 8 Gb Fibre Channel mezzanine card is installed in slot 2, at least one
Fibre Channel connection blade must be installed in fabric 3.
– If a 40 Gb Infiniband mezzanine card is installed in slot 2, Infiniband
connection blades should be installed in fabrics 3 and 4.
I In this case the dual ports of the mezzanine card will be available and
one of two ports will be connected to connection blade in fabric 3, the
other one will be connected to connection blade in fabric 4.
System unit
Connection blade slots Server Blade
Mezzanine
card
Fabric 1
CB1:
1 Gb Ethernet
or
10 Gb Ethernet
CB2:
1 Gb Ethernet
or
10 Gb Ethernet
Onboard
LAN controller
---
Fabric 2
CB3: CB4:
Mezzanine
card 1
Fabric 3
CB5:
Fibre Channel
CB6:
Fibre Channel
Mezzanine
card 2
FC 8 Gb 2 port
Fabric 4
CB7: CB8:
System unit
Connection blade slots Server Blade
Mezzanine
card
Fabric 1
CB1:
1 Gb Ethernet
or
10 Gb Ethernet
CB2:
1 Gb Ethernet
or
10 Gb Ethernet
Onboard
LAN controller
---
Fabric 2
CB3: CB4:
Mezzanine
card 1
Fabric 3 Infiniband (CB5/6)
Mezzanine
card 2
IB 40 Gb 2 port
Fabric 4
Infiniband (CB7/8)
