5.1.2 SATA backplane (only for hot-plug variant)
Part number: S26361-D2266-A10
1 Connector SATA cable for hard disk 2
2 Connector SEP IPMB cable
3 Connector SATA LED cable
4 Connector SATA cable for hard disk 1
5 Connector power cable
1
2
3
4
5
