24 Operating Manual RX100 S7
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3034
Chipset Intel
®
C202
Processor quantity and
type
1x Intel
®
Xeon
®
E3 family / Pentium
®
/ Core i3
Memory slots 4 (2 banks with 2 DIMMs each)
Memory slot type DIMM (DDR3) UDIMM
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes with 2 channels and 2 slots per channel
USB connectors 7 x USB (2x front, 4x rear, 1x internal for UFM)
Graphics (15-pin) 1 x VGA
Serial (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet
Management LAN
(RJ45)
1 x dedicated management LAN port for iRMC S3
(10/100/1000 Mbit/s); management LAN traffic can
be switched to shared onboard Gbit LAN port
