66 Operating Manual RX100 S7
Starting up and operation
6.1.2 Rear of server
ID indicator, Global Error indicator, and CSS indicator
Figure 9: Indicators on the connector panel: CSS, Global Error and ID indicators
1 CSS, Global Error and ID indicators (yellow, orange and blue)
Global Error indicator (orange)
– Lights up orange if a prefailure event has been detected that
requires (precautionary) service intervention.
– Flashes orange if an error was detected that requires service
intervention.
– Does not light up if there is no critical event.
If the event is still acute after a power failure, the indicator is
activated after the restart.
The indicator also lights up in standby mode.
You can find more details on the indicated errors in the System
Event Log (SEL), on the ServerView Local Service Panel, in the
ServerView Operations Manager or via the iRMC S3's Web
interface.
/
!
