RX100 S7 Operating Manual 27
Functional overview
Dimensions / Weight
Ventilation clearance
At least 200 mm on the front and rear
Ambient conditions
Condensation during operation must be avoided!
Width 431 mm (without projecting parts)
Depth 557 mm (without projecting parts)
Installation depth in
rack
572 mm
Height 42.5 mm or 1 HU
Weight up to 13 kg
Weight notes Weight may vary depending on actual configuration
Rack mounting kit Rack mounting kit as option
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 15 °C ... 35 °C
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85% (non condensing)
