24 Operating Manual
RX100 S8
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3229
Chipset Intel
®
C226
Processor quantity and
type
1x Intel
®
Xeon
®
E3-1200v3 family / Pentium
®
/
Celeron
®
/ Core i3
Memory slots 4 (2 banks with 2 DIMMs each)
Memory slot type DIMM (DDR3L) UDIMM
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes Dual channel support. For dual channel
performance, a minimum of 2 memory modules has
to be ordered. Capacity per channel has to be the
same.
USB 2.0 connectors 4 (2x rear, 2x internal)
USB 3.0 connectors 4 (2x front, 2x rear)
Graphics (15-pin) 1 x VGA (rear); 1x front VGA as an option
Serial (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 1 x standard LAN, 1 x shared LAN
