66 Operating Manual
RX100 S8
Starting up and operation
LAN indicators
Figure 10: LAN indicators
LED Indicator Description
1LAN
link/transfer
Lights up green when a LAN connection exists.
Remains dark when no LAN connection exists.
Flashes green when LAN transfer takes place.
2 LAN speed Lights up yellow in the event of a LAN transfer rate
of 1 Gbit/s
Lights up green in the event of a LAN transfer rate of
100 Mbit/s.
Remains dark in the event of a LAN transfer rate of
10 Mbit/s.
