Fujitsu PRIMERGY RX100 S8 - 6 Starting up and operation; 6.1 Control elements and indicators

RX100 S8 Operating Manual 59
6 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 33.
6.1 Control elements and indicators
6.1.1 Front of the server
Figure 6: Controls and indicators on the front panel
1 Optical drive activity indicator 6 Global Error indicator
2 Reset button 7 Hard disk activity indicator
3 NMI button 8 On/Off button / power-on indicator
4 ID button / ID indicator 9 Power-off indicator (AC
connected)
5 CSS indicator
햲
햴햳 햵
햶
햷햸 햹햺
