54 Operating Manual
RX100 S8
Hardware installation
5.4.1 Using cable ties (standard PSU)
You can secure the power cord using a cable tie to ensure that the insulated
connector cannot be disconnected from the server accidentally. The cable tie is
included in the accessories pack that is delivered together with the server.
Figure 4: Using cable ties
Ê Thread the cable tie through the eye (1).
Ê Pull the cable tie tight to secure the power cord.
The insulated connector cannot now be disconnected from the server
accidentally.
You can loosen the cable tie by opening the small locking lever (2).
햳
햲
