RX100 S8
Operating Manual 27
Functional overview
Dimensions / Weight
Ventilation clearance
At least 200 mm on the front and rear
Ambient conditions
Condensation during operation must be avoided!
Status LED at system
rear side
System status (orange)
CSS (orange)
Identification (blue)
LAN connection (green)
LAN speed (green / yellow)
Width
482.6 mm (bezel) / 435.4 mm (body)
Depth 610.75 mm
Installation depth in
rack
558.75 mm (without projecting parts)
Height 42.8 mm / 1 HU
Weight
approx. 8.8 kg – 13.2 kg
Weight notes Weight may vary depending on actual configuration
Rack mounting kit Rack mounting kit as option
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5 °C ... 40 °C (with Cool-safe
®
ATD)
10 °C ... 35 °C (without Cool-safe
®
ATD)
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85% (non condensing)
