30 Operating Manual
RX100 S8
Functional overview
Screen resolution
The screen resolutions in the following table refer to the graphics controller on
the system board. The graphics controller is integrated in the iRMC S4
(integrated Remote Management Controller).
If you are using an external graphics controller, you will find details of supported
screen resolutions in the Operating Manual or Technical Manual supplied with
the graphics controller.
Screen resolution
(pixel)
Maximum refresh
rate (Hz)
Max. number of colours
640x480 85 32 bit
800x600 85 32 bit
1024x768 75 32 bit
1152x864 60 16 bit
1280x1024 60 24 bit
1600x1200 60 16 bit
1920x1080 60 16 bit
