Fujitsu PRIMERGY RX1330 M3

24 Operating Manual RX1330 M3
Functional overview
Onboard or integrated controllers
Slots
Management LAN
(RJ45)
1 x dedicated management LAN port for iRMC S4
(10/100/1000 Mbit/s); management LAN traffic can
be switched to shared onboard Gbit LAN port
RAID Controller Modular Host Bus Adapter with "Integrated RAID"
(IR). RAID levels 0 and 1 are supported for internal
HDD configurations.
Modular RAID 0/1 controller with "MegaRAID
functionality" (integrated MegaRAID).
RAID levels 0, 1, 10, 5 and 50 are supported for
internal HDD configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (MegaRAID).
RAID levels 0, 1, 10, 5, 50, 6 and 60 are supported
for internal HDD configurations.
SATA Controller A 6-port SATA controller is integrated on the system
board; up to four SATA HDDs can be connected to
the controller. The LSI Embedded MegaRAID
software (SATA Software RAID) supports RAID
levels 0, 1 and 10.
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon TCG V1.2 compliant (option)
Infineon TCG V2.0 compliant (option)
PCI Express 3.0 x8 2 x low-profile length 175 mm; one slot may be
occupied by Modular RAID
PCI Express 3.0 x4
(mech. x8)
1 x low-profile
Slot notes Optional support of 1x full height PCIe Gen3 x8 card,
instead of 1x PCIe Gen3 x4 and 1x PCIe Gen3 x8.
