Fujitsu PRIMERGY RX1330 M3

RX1330 M3 Operating Manual 25
Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
4/8/10 x 2.5-inch for hot-plug SAS/SATA HDD
modules or SATA SSD modules
4 x 3.5-inch for hot-plug SAS/SATA HDD modules
Accessible drive bays 1 x 5.25/0.4-inch for 1x ultra slim ODD
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/Off button
ID button
Reset button
NMI button
Status LEDs Global Error indicator (orange)
ID indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)
CSS indicator (orange)
Status LED at system
rear side
Global error / CSS / ID indicator (orange / orange /
blue)
LAN connection indicator (green)
LAN speed indicator (green/yellow)
