Fujitsu PRIMERGY RX1330 M3 - Front Panel Status Indicators

RX1330 M3 Operating Manual 59
Starting up and operation
6.1.1.2 Indicators on the front panel
Figure 9: Indicators on the front panel
Figure 10: Indicators on the front panel on QRL
Pos. Label Indicator Status Description
1 ID
ID
indicator,
see also
"iRMC-
related
status
signals" on
page 61
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web frontend or
the ID button on the front panel for
easy identification.
blue
flashing
The server has been highlighted
for easy identification using the
iRMC (AVR) with disabled local
VGA output.
